$7,999.00
Apply for up to $5,000
Tax included. Shipping calculated at checkout.
Available on backorder
SyncDrive Pro motor delivers 85Nm of torque and tuneable support ratios up to 400 percent. Smart Assist technology creates smooth pedal assistance that engages instantly when human power is applied, giving you reliable performance on steep climbs and at low speeds.
Optimised Maestro suspension for 29-inch wheels with 140mm rear/ 150mm front travel to roll over rough terrain with balance and stability, giving you more momentum for technical climbs and the confidence to fly on fast, rugged singletrack descents.
Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style. You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
174 cm 182 cm 190 cm 198 cm
E-BIKE SPECIFICATIONS
Motor: SyncDrive Pro, 85Nm, powered by Yamaha
Controller: RideControl Ergo 3, grip integrated
Display: RideControl GO, frame integrated LED display ANT+ Wireless display compatible
Battery: Giant EnergyPak 750Wh, Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible
SPECIFICATIONS
Frame: ALUXX SL-grade Aluminum, Advanced Forged Composite linkage, 140mm Maestro Suspension System, ‘Boost’ 148×12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible
Fork: RockShox 35 Gold RL DebonAir, 150mm travel, 44mm offset, MotionControltm rebound and lockout control, 15×110 Boost, Maxle Stealth, e-MTB optimized
Shock: Rock Shox Deluxe Select R, DebonAir, 185×52.5mm Trunnion mount, custom tuned, recommended sag: 30%
Handlebar: Giant Contact 35 Trail
Grips: Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
Stem: Giant Contact SL 35
Seat: Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm, M: 150mm travel / 30.9 x 440mm, L: 170mm travel / 30.9 x 450mm, XL: 170mm travel / 30.9 x 450mm
Saddle Giant: Romero E
Pedals: Flat pedal
Shifters: Shimano Deore
Front Derailleur: MRP HD2 co-moulded chain guide
Rear Derailleur: Shimano Deore, 12-speed
Brakes: Shimano BR-M420, 4-piston, hydraulic disc, 203mm
Brake Levers: Shimano Deore, I-spec EV
Cassette: Shimano CS-M6100-12, 10-51T, 12-speed
Chain: KMC e.12 Turbo, EcoProteq, e-bike optimized
Crankset: Praxis Wave 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (Q-factor=168, S:160, M/L:165, XL:170)
Bottom Bracket: N/A
Rims: Giant AM 29″
Hubs: Shimano MT410 Boost, Center-Lock, [F] 110×15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes: Sapim E-Lite [R] Race [F], e-bike optimized
Tyres: Maxxis Minion DHF 29×2.6″ foldable, Tubeless, EXO+, 3C MaxxTerra [F]Maxxis Dissector 29×2.6″ Foldable, Tubeless, EXO+, 3C MaxxTerra [R]
Extras: Tubeless kit (liquid, valves, levers)
Lock: Torx 25 Battery Lock with built-in Torque Limiter
